HY-Motor Run Capacitor (CBB60) is a key component to ensure the reliable operation of single-phase motors in harsh environments such as air conditioners, pumps and compressors. Made of self-healing metallized polypropylene film, it provides long-lasting performance and stability, which is critical for the continuous operation of the motor.

HY-Motor Run Capacitor (CBB60) is designed for continuous operation of single-phase motors, which is critical in applications such as air conditioners, compressors, pumps and power tools. It is essential to provide the necessary phase shift and maintain power factor correction, allowing the motor to start reliably and run efficiently under load. Selecting a high-quality motor run capacitor directly affects motor performance, energy efficiency and the life of the entire system. The HY series meets the core needs for stability and durability in environments where motor function is critical.

The HY-Motor Run Capacitor (CBB60) is characterized by its superior manufacturing process. The self-healing metallized polypropylene film technology can automatically isolate small internal faults, prevent failures, and significantly extend its service life. The capacitor element adopts non-inductive winding to ensure minimum loss and stable capacitance value, which is essential to maintain the stability of motor torque. The entire wound element is fully immersed in high-grade resin. Full encapsulation provides excellent protection against moisture, mechanical vibration and thermal stress, and enhances the resilience of the capacitor.

Safety features are an integral part of the HY-Motor Run Capacitor (CBB60) design. Enclosed in a self-extinguishing plastic housing, the component actively prevents the spread of flame in the unlikely event of an internal fault, significantly improving operational safety. An integrated discharge resistor continues to operate after the motor is de-energized, safely discharging stored energy and protecting technicians during maintenance. An optional plastic cover provides additional terminal protection when required.

Rugged hardware options ensure installation flexibility. HY-Motor Run Capacitor (CBB60) features a flat bottom design and is equipped with M8×1 metal fixing studs to ensure secure installation. Reliable Faston terminals (0.8×6.35mm) are available in single-ended or double-ended configurations with a standard center distance of p=13.2mm ±0.5mm to ensure compatibility. HY-Motor Run Capacitor (CBB60) is compatible with single-pole and double-pole cable terminations and can adapt to various wiring methods in motor circuits.
